Product Details:
Payment & Shipping Terms:
|
| Product: | Carbon Enduro Full Suspension Bike Frame | Material: | High-Grade Carbon Fiber |
|---|---|---|---|
| Wheel Size: | 27.5er Boost Or 29er | Wheel Travel: | 150mm |
| Shock Size: | 200x57mm | Dropout: | 148x12mm |
| Max Tire: | 27.5er X2.80 Or 29erx2.35 | Sizes: | 17"/19" |
| Weight: | 2500+-45grams(17") | OEM: | Acceptable |
27.5er Boost Carbon Electric Bike Frame Enduro Full Suspension Ebike Shimano E8000
Features:
1. 27.5er Boost Full Carbon Suspension EBike Frame , fits with Shimano E8000 mid-drive motor
2. Built-in Integrated battery Box in Downtube.
2. AM/Enduro riding style with Wheel Travel: 150mm . Shock Size 200x51mm
3. Wheel size 27.5er boost, Dropout 148x12mm with max. tire 27.5x2.80 or 29x2.35
5. UD/3K matte black or customized painting for OEM orders.
6. 2 years' warranty
Technical Data:
| Product | 27.5er Carbon Full Suspension Electric Bike Frame |
| Model: | E1065 |
| Material | High Grade Carbon Fiber |
| Motor Compatible | Shimano E8000 mid-drive system |
| Battery Box | Built-in Integrated battery box in Downtube( open at lower) |
| Wheel | 27.5" boost |
| Rear Wheel Travel | 150mm |
| Shock Size | 200x51mm |
| Rear Dropout | 148x12 thru axle |
| Max. Tire | 27.5er x 2.80 or 29erx2.35 |
| Headtube | tapered (1-1/8" upper, 1-1/2" lower) |
| Seatpost | 31.6 mm |
| Headtube Angle | 67 degree |
| Reach | 424.2(17"), 440.7(19") |
| Stack | 629(17"), 638.2(19") |
| Brake | Disc(post mount,180mm) |
| Standard: | ISO9001, EN |
| Weight: | 2500+-50 grams(17") |
| Routing | Internal cable rounting |
| Pivot Linkage | Premium Sealed Bearings |
| Size: | 17", 19" |
| Riding Style | Electric AM/Enduro |
| Surface | UD,3K, Cutomized painting acceptable |
| OEM | Acceptable |
| Warranty | 2 years |
Our OEM Ebike Frames Advantage:
More motors appliable:We have interfaces for Shimano, Brosch, Brose, Bafang, Vinka, Yamaha, Panasonic etc. and are able to make ebike frames with wide choice of motors in market.
More Models optional: Dozens ebike frames with open mold availablef or customer's choice. and wide selection of aluminum tubes to satisfy customized oem design and processing.
Full Range of Category: Different range of ebike frames covering Full Suspension, E-mtb, e-citibike in aluminum and carbon material.
Customized processing: OEM production and Customized painting are welcome.
